Curta手持机械式计算机器3D图纸(Type 1 ca 1930)（ID:555579）
83
0
0
| # | 文件名称 | 文件大小 |
|---|---|---|
| 1 | +必看说明+.txt | 2.22 KB |
| 2 | 10.001 Step Drum.SLDPRT | 307 KB |
| 3 | 10.002 Upper Main Housing.SLDPRT | 1.7 MB |
| 4 | 10.003 Main Shaft.SLDPRT | 78.9 KB |
| 5 | 10.004 Spider Spring.SLDPRT | 126 KB |
| 6 | 10.005 Tens Carry Lever Result Side.SLDPRT | 146 KB |
| 7 | 10.005b Tens Carry Block Result Side assy.SLDASM | 176 KB |
| 8 | 10.006 Tens Carry Lever Units Side.SLDPRT | 161 KB |
| 9 | 10.006b Tens Carry Block Units Side assy.SLDASM | 178 KB |
| 10 | 10.007 Tens Carry Lever Spring.SLDPRT | 211 KB |
| 11 | 10.008 Numeral Dial Axle.SLDPRT | 97.8 KB |
| 12 | 10.009 Tens Bell Body.SLDPRT | 216 KB |
| 13 | 10.010 Step Drum Positioning Tongue.SLDPRT | 69.7 KB |
| 14 | 10.011 Upper Main Casting.SLDPRT | 511 KB |
| 15 | 10.012 Crank Handle.SLDPRT | 974 KB |
| 16 | 10.014a Trasmision Shaft 1.SLDPRT | 55.8 KB |
| 17 | 10.014b Trasmision Shaft 2.SLDPRT | 70 KB |
| 18 | 10.014c Trasmision Shaft 3.SLDPRT | 71.8 KB |
| 19 | 10.014d Trasmision Shaft 4.SLDPRT | 65.7 KB |
| 20 | 10.015 Retaining Screw for 10.010 (M1.7-0.35 x 5.8 x 3.8).SLDPRT | 132 KB |
| 21 | 10.016 Counter Lock Plunger.SLDPRT | 78.2 KB |
| 22 | 10.018 Ten Carry Lever Bearing Block.SLDPRT | 102 KB |
| 23 | 10.019 Numeral Dial Pin (round).SLDPRT | 44.1 KB |
| 24 | 10.019 Speed Roll Pin.SLDPRT | 45.2 KB |
| 25 | 10.020 Guiding Sleeve.SLDPRT | 87.4 KB |
| 26 | 10.021 Numeral Dial Pin.SLDPRT | 53.6 KB |
| 27 | 10.022 Crank Bolt.SLDPRT | 73.8 KB |
| 28 | 10.023 Reversing Lever Spring (3.5-500gr Kd=4500 Kg.cm2).SLDPRT | 410 KB |
| 29 | 10.024 Eraser Fixer Pin.SLDPRT | 75.4 KB |
| 30 | 10.025 Main Bearing Sleeve.SLDPRT | 437 KB |
| 31 | 10.026 Carriage Holding Nut.SLDPRT | 291 KB |
| 32 | 10.027 Carriage Locating Pin.SLDPRT | 76.8 KB |
| 33 | 10.028 Baseplate.SLDPRT | 77.1 KB |
| 34 | 10.029 Numeral Roll.SLDPRT | 639 KB |
| 35 | 10.030 Clearing Plate.SLDPRT | 207 KB |
| 36 | 10.031 Tens Bell Shim.SLDPRT | 64 KB |
| 37 | 10.032 Guiding Sleeve.SLDPRT | 88.7 KB |
| 38 | 10.033 Flat Spring.SLDPRT | 114 KB |
| 39 | 10.034 Clearing Lever New (plastic).SLDPRT | 204 KB |
| 40 | 10.034 Clearing Lever.SLDPRT | 193 KB |
| 41 | 10.035 Spring Sleeve.SLDPRT | 85 KB |
| 42 | 10.036 CirClip.SLDPRT | 77.2 KB |
| 43 | 10.038 Trasmissing Gear 1.SLDPRT | 88.5 KB |
| 44 | 10.039 Triggering Stud.SLDPRT | 121 KB |
| 45 | 10.040 Carriage Casting (new).SLDPRT | 346 KB |
| 46 | 10.041 Pressure Sleeve.SLDPRT | 74.7 KB |
| 47 | 10.042 Compensation Sleeve.SLDPRT | 67.6 KB |
| 48 | 10.043 Numeral Dial 1.SLDPRT | 873 KB |
| 49 | 10.045 Numeral Dial 2.SLDPRT | 841 KB |
| 50 | 10.046 Decimal Marker.SLDPRT | 80.1 KB |
| 51 | 10.047 Decimal Marker Spring (Kd=45 Kg.mm2).SLDPRT | 447 KB |
| 52 | 10.048 Cylindrical Screw (M1.7-0.35 x 2.6).SLDPRT | 70.8 KB |
| 53 | 10.049 Locking Gear.SLDPRT | 87.5 KB |
| 54 | 10.050 Carriage Pressure Spring (6.3-320gr Kd=4600 Kg.cm2).SLDPRT | 453 KB |
| 55 | 10.051 Compensation Sleeve.SLDPRT | 60.5 KB |
| 56 | 10.052 Five Toothed Gear.SLDPRT | 201 KB |
| 57 | 10.053 Tens Carry Gear 2.SLDPRT | 88.5 KB |
| 58 | 10.054 Pressure Sleeve.SLDPRT | 79.8 KB |
| 59 | 10.055 Guiding Sleeve.SLDPRT | 88.8 KB |
| 60 | 10.056 Guiding Sleeve.SLDPRT | 90.9 KB |
| 61 | 10.057 Setting Knob.SLDPRT | 174 KB |
| 62 | 10.058 Locking Spring.SLDPRT | 1.41 MB |
| 63 | 10.059 Shouldered Screw (M1.7-0.30 x 4.85 x 2).SLDPRT | 98.5 KB |
| 64 | 10.061 Setting Shaft.SLDPRT | 232 KB |
| 65 | 10.062 Base Ring.SLDPRT | 2.78 MB |
| 66 | 10.064 Support Column.SLDPRT | 69.9 KB |
| 67 | 10.065 Reversing Lever Shaft.SLDPRT | 79.6 KB |
| 68 | 10.066 Reversing Knob.SLDPRT | 120 KB |
| 69 | 10.067 Reversing Fork.SLDPRT | 135 KB |
| 70 | 10.068 Steering Ring.SLDPRT | 119 KB |
| 71 | 10.069 Spring Pin (M1 x 5.5).sldprt | 112 KB |
| 72 | 10.069 Tension Pin (M1 x 5.5).sldprt | 111 KB |
| 73 | 10.070 Step Drum Positioning Spring (half).SLDPRT | 282 KB |
| 74 | 10.070 Step Drum Positioning Spring.SLDPRT | 254 KB |
| 75 | 10.071 Locking Ring.SLDPRT | 119 KB |
| 76 | 10.072 Step Drum Engagement Pin.SLDPRT | 52.3 KB |
| 77 | 10.073 Setting Knob Spring (Kd=6500 Kg.cm2).SLDPRT | 481 KB |
| 78 | 10.074 Countersunk Screw (M1.2-0.25 x 2.8)-.SLDPRT | 71.5 KB |
| 79 | 10.075 Guiding Screw (M1.4-0.3 x 1.6).SLDPRT | 115 KB |
| 80 | 10.076 Result Counter Segment (10 teeth).SLDPRT | 101 KB |
| 81 | 10.077 Lower Main Casting.SLDPRT | 262 KB |
| 82 | 10.078 Result Counter Segment (1 tooth).SLDPRT | 110 KB |
| 83 | 10.079 Result Counter Segment (9 teeth).SLDPRT | 121 KB |
| 84 | 10.080 Result Counter Segment (2 teeth).SLDPRT | 114 KB |
| 85 | 10.081 Result Counter Segment (8 teeth).SLDPRT | 120 KB |
| 86 | 10.082 Result Counter Segment (3 teeth).SLDPRT | 116 KB |
| 87 | 10.083 Result Counter Segment (7 teeth).SLDPRT | 120 KB |
| 88 | 10.084 Result Counter Segment (4 teeth).SLDPRT | 117 KB |
| 89 | 10.085 Collar.SLDPRT | 548 KB |
| 90 | 10.086 Clear Locking Pin Spring (Kd=8000 kg.cm2).SLDPRT | 381 KB |
| 91 | 10.087 Result Counter Segment (6 teeth).SLDPRT | 118 KB |
| 92 | 10.088 Carriage Ring.SLDPRT | 4.26 MB |
| 93 | 10.089 Carriage Cage.SLDPRT | 817 KB |
| 94 | 10.090 Result Counter Segment (5 teeth).SLDPRT | 117 KB |
| 95 | 10.091 Turns Counter Segment (1 tooth).SLDPRT | 115 KB |
| 96 | 10.093 Clearing Lever Rivet.SLDPRT | 97.6 KB |
| 97 | 10.094 Rivet Washer.SLDPRT | 74.4 KB |
| 98 | 10.095 Spring Housing for 10.024.SLDPRT | 53 KB |
| 99 | 10.096 Turns Counter Segment (9 teeth).SLDPRT | 120 KB |
| 100 | 10.097 Circlip for Trasmission shaft.SLDPRT | 82.7 KB |
| 101 | 10.098 Suplement Washer.SLDPRT | 71 KB |
| 102 | 10.099 Suplement Washer.SLDPRT | 73.8 KB |
| 103 | 10.100 Tens Carry Disc for Turns Counter.SLDPRT | 112 KB |
| 104 | 10.101 Tens Carry Disc for Turns Counter.SLDPRT | 112 KB |
| 105 | 10.102 Distance Disc.SLDPRT | 66.7 KB |
| 106 | 10.103 Distance Disc.SLDPRT | 72.8 KB |
| 107 | 10.104 Locking Disc for Turns Counter.SLDPRT | 74.7 KB |
| 108 | 10.105 Tens Carry Locking Disc for Turns Counter.SLDPRT | 73.5 KB |
| 109 | 10.106 Locking Disc for Results Counter.SLDPRT | 74.5 KB |
| 110 | 10.107 Tens Carry Locking Disc for Result Counter.SLDPRT | 73.1 KB |
| 111 | 10.109 Pin Screw (M1.4-0.3 x 1.4).SLDPRT | 96.8 KB |
| 112 | 10.110 Compensation Sleeve.SLDPRT | 61.4 KB |
| 113 | 10.111 Zero Positioner Disc.SLDPRT | 562 KB |
| 114 | 10.112 Zero Positioner Roller.SLDPRT | 72 KB |
| 115 | 10.113 Non Return Pawl.SLDPRT | 83.6 KB |
| 116 | 10.114 Zero Positioner Lever.SLDPRT | 90.5 KB |
| 117 | 10.115 Zero Positioner Spring.SLDPRT | 897 KB |
| 118 | 10.116 Zero Positioner Shoulder Screw (M1.7-0.3 x 9.4 x 1.6).SLDPRT | 80.7 KB |
| 119 | 10.118 Disc Spring Clip.SLDPRT | 186 KB |
| 120 | 10.119 Step Drum Fastening Segment.SLDPRT | 71.5 KB |
| 121 | 10.120 Supporting Disc.SLDPRT | 84.6 KB |
| 122 | 10.121 Non Return Pawl Bush.SLDPRT | 90.1 KB |
| 123 | 10.124 Sealing Ring.SLDPRT | 102 KB |
| 124 | 10.125 Zero Positioner Lever Bush.SLDPRT | 79.2 KB |
| 125 | 10.126 Decorative Cover.SLDPRT | 80.5 KB |
| 126 | 10.129 Pressure Ring.SLDPRT | 66.2 KB |
| 127 | 10.130 Large Rubber Insert.SLDPRT | 52.4 KB |
| 128 | 10.131 Small Rubber Insert.SLDPRT | 57.8 KB |
| 129 | 10.133 Special Circlip.SLDPRT | 76.4 KB |
| 130 | 10.134 Carriage Stop Pin.SLDPRT | 66.7 KB |
| 131 | 10.135 Setting Shaft Bearing Pin.SLDPRT | 69.9 KB |
| 132 | 10.136 Holding Plate.SLDPRT | 69 KB |
| 133 | 10.137 Lower Reversing Shaft Sleeve.SLDPRT | 48.8 KB |
| 134 | 10.138 Upper Reversing Shaft Sleeve.SLDPRT | 56.5 KB |
| 135 | 10.140 Guiding Sleeve.SLDPRT | 92.4 KB |
| 136 | 10.141 Pressure Sleeve.SLDPRT | 76.2 KB |
| 137 | 10.142 Toothed Clearing Segment (inner).SLDPRT | 224 KB |
| 138 | 10.142 Toothed Clearing Segment (outer).SLDPRT | 221 KB |
| 139 | 10.143 Shim for Clearing Plate.SLDPRT | 66.3 KB |
| 140 | 10.145 Steel Ball 2.0mm.SLDPRT | 167 KB |
| 141 | 10.146 Balancing Disc.SLDPRT | 55.4 KB |
| 142 | 10.147 Bearing Bush.SLDPRT | 71.1 KB |
| 143 | 10.148 Cylindrical Pin (1.0x10).SLDPRT | 61.7 KB |
| 144 | 10.149 Cylindrical Pin (0.8x4).SLDPRT | 74.6 KB |
| 145 | 10.150 Cylindrical Pin (1.5x5).SLDPRT | 82.2 KB |
| 146 | 10.152 Spring Washer.SLDPRT | 108 KB |
| 147 | 10.153 Compensation Ring.SLDPRT | 66.3 KB |
| 148 | 10.154 Number Label.SLDPRT | 605 KB |
| 149 | 10.155 Seal Ring.SLDPRT | 119 KB |
| 150 | 10.156 Case Cap Mark (old).SLDPRT | 287 KB |
| 151 | 10.156 Case Cap Mark.SLDPRT | 697 KB |
| 152 | 10.158 Serial Number Plate.SLDPRT | 2.47 MB |
| 153 | 10.160 Baseplate Type 2.SLDPRT | 1.67 MB |
| 154 | 10.161 Strap Screw (M8-0.75 x 2.5).SLDPRT | 227 KB |
| 155 | 10.162 Strap Screw Washer (leather).SLDPRT | 176 KB |
| 156 | 10.163 Link.SLDPRT | 123 KB |
| 157 | 10.203 Numeral Dial 1 assy.SLDASM | 311 KB |
| 158 | 10.204 Numeral Dial 2a assy.SLDASM | 300 KB |
| 159 | 10.205 Numeral Dial 2b assy.SLDASM | 302 KB |
| 160 | 10.206 Tens Bell assy.SLDASM | 199 KB |
| 161 | 10.207 Trasmision Shaft 1 assy.SLDASM | 77.9 KB |
| 162 | 10.208 Trasmision Shaft 2 assy.SLDASM | 83.1 KB |
| 163 | 10.209 Trasmision Shaft 3 assy.SLDASM | 82.9 KB |
| 164 | 10.210 Curta Type 1 assy.SLDASM | 12 MB |
| 165 | 10.211 Reversing Lever assy.SLDASM | 97.3 KB |
| 166 | 10.212 Setting shaft assy.SLDASM | 334 KB |
| 167 | 10.213 Step Drum assy.SLDASM | 353 KB |
| 168 | 10.214 Main Shaft Complete assy.SLDASM | 350 KB |
| 169 | 10.215 Housing assy.SLDASM | 1.73 MB |
| 170 | 10.216 Trasmision Shaft 4 assy.SLDASM | 81 KB |
| 171 | 10.218 Reversing Gear.SLDASM | 97.1 KB |
| 172 | 10.219 Double Seting Gear.SLDASM | 93.4 KB |
| 173 | 10.220 Tens Carry Gear assy.SLDASM | 101 KB |
| 174 | 10.221 Products Units Locking Gear.SLDASM | 83.6 KB |
| 175 | 10.222 Quotient Units Locking Gear.SLDASM | 82.6 KB |
| 176 | 10.223 Main Shaft assy.SLDASM | 80.6 KB |
| 177 | 10.224 Non Return Pawl assy.SLDASM | 94.3 KB |
| 178 | 10.225 Zero Positioner Lever assy.SLDASM | 81.3 KB |
| 179 | 10.226 Carriage Casting assy.SLDASM | 275 KB |
| 180 | 10.227 Upper Main Casting assy with Tens Bell assy.SLDASM | 474 KB |
| 181 | 10.228 Container assy.SLDASM | 1.2 MB |
| 182 | 10.228a Container Lid.SLDPRT | 348 KB |
| 183 | 10.228b Container Base.SLDPRT | 1.56 MB |
| 184 | 10.229 Main Bearing Sleeve assy.SLDASM | 345 KB |
| 185 | 10.230 Trasmission Gear assy.SLDASM | 84.9 KB |
| 186 | 10.231 Lower Main Casting assy.SLDASM | 1.25 MB |
| 187 | 10.232 Main Assembly Step 1.SLDASM | 1.95 MB |
| 188 | 10.233 Main Assembly Step 2.SLDASM | 2.87 MB |
| 189 | 10.234 Main assembly Step 3.SLDASM | 7.2 MB |
| 190 | 10.236 Trasmission Shaft 4 complete assy.SLDASM | 156 KB |
| 191 | 10.237 Trasmission Shaft 1 complete assy.SLDASM | 152 KB |
| 192 | 10.238 Trasmission Shaft 2 complete assy.SLDASM | 159 KB |
| 193 | 10.239 Trasmission Shaft 3 complete assy.SLDASM | 151 KB |
| 194 | 10.240 Setting Knob complete.SLDASM | 807 KB |
| 195 | 10.241 Reversing Lever with Shaft assy.SLDASM | 453 KB |
| 196 | 10.242 Crank (Delrin) with Pin.SLDASM | 219 KB |
| 197 | 10.242 Crank (Delrin).SLDPRT | 357 KB |
| 198 | 10.243 Carriage assy Step 1.SLDASM | 2.04 MB |
| 199 | 10.244 Clearing Plate assy.SLDASM | 782 KB |
| 200 | 10.245 Crank assy.SLDASM | 485 KB |
| 201 | 10.246 Zero Positioner assy.SLDASM | 151 KB |
| 202 | 10.248 Upper Main Casting with Pins.SLDASM | 261 KB |
| 203 | 10.249 Baseplate assy.SLDASM | 367 KB |
| 204 | 10.250 Setting Knob with Guiding Screw.SLDASM | 100 KB |
| 205 | 10.301 Decimal Marker assy.SLDASM | 497 KB |
| 206 | 2037 Zero Position Roller Screw (M1.7-0.35 x 5.4 x 2.4).SLDPRT | 135 KB |
| 207 | 2074 Hexagonal Nut (M1.7-0.35 x 1.4).SLDPRT | 103 KB |
| 208 | 2118 Retaining Screw (M1.4-0.3 x 1.1).SLDPRT | 105 KB |
| 209 | A01 Taper Pin (ISO 2339 - A - 1.0 x 14 - St).sldprt | 86.7 KB |
| 210 | A09 Countersunk Screw (M2-0.4 x 18 - 6S).sldprt | 153 KB |
| 211 | A18 Steel Ball 1.0mm.SLDPRT | 162 KB |
| 212 | B01 Cylindrical Screw (M1.4-0.3 x 3 - 3S).sldprt | 159 KB |
| 213 | B05 Cylindrical Screw (M1.4-0.3 x 5 - 5S).sldprt | 168 KB |
| 214 | B10 Hexagonal Nut (M1.4-0.3 x 1).SLDPRT | 103 KB |
| 215 | B14 Cylindrical Screw (M1-0.25 x 3 - 3S).sldprt | 157 KB |
| 216 | C18 Taper Pin (ISO 2339 - A - 1 x 8 - St).sldprt | 87.5 KB |
| 217 | C26 Cylindrical Screw (M1.4-0.3 x 2 - 2S).sldprt | 137 KB |
| 218 | Carriage01.JPG | 500 KB |
| 219 | Carriage02.JPG | 473 KB |
| 220 | Carriage03.JPG | 494 KB |
| 221 | Complete Group.JPG | 472 KB |
| 222 | Curta01.JPG | 469 KB |
| 223 | Curta02.JPG | 482 KB |
| 224 | Curta03.JPG | 649 KB |
| 225 | Curta04.JPG | 506 KB |
| 226 | Curta05.JPG | 550 KB |
| 227 | Curta06.JPG | 615 KB |
| 228 | Curta07.JPG | 434 KB |
| 229 | Curta08.JPG | 585 KB |
| 230 | Curta09.JPG | 512 KB |
| 231 | Curta10.JPG | 439 KB |
| 232 | Curta11.JPG | 699 KB |
| 233 | D10 Steel Ball 2.0mm.SLDPRT | 166 KB |
| 234 | D11 Taper Pin (ISO 2339 - A - 0.6 x 4 - St).sldprt | 97 KB |
| 235 | E03 Steel Ball 1.8mm.SLDPRT | 164 KB |
| 236 | 【 屿双网 www.ysh3d.com 】 更多【资料】【图档】.url | 177 B |
| 237 | 公众号免费下载.jpg | 79 KB |
免责申明:
本网站模型由用户自行上传，如权利人发现存在误传其作品情形，请及时与本站联系。
免费下载
此图纸可免费下载
图纸ID：555579
文件大小：89.31M
软件版本：SOLIDWORKS 2017
图纸格式：sldprt,sldasm
参数/编辑：可修改，包括参数
上传时间：2024-02-26
图纸介绍：
发布者
屿双网小匠
作品: 13827
粉丝: 65
![JCXE-W光栅尺[JCXE50-W1]](https://yushuangwang2.oss-accelerate.aliyuncs.com/fileimg/m67baf77a3561f/01_home.jpg)
提示
×
下载该图档需要消耗0金币！
确认下载
客服
签到
分享
