3V、0.8A太阳能电池板、3V超级电容器外壳（ID:696217）

人与自然 / 自然 / 3V、0.8A太阳能电池板、3V超级电容器外壳

平面图

3D视图

文件列表

屿双网

屿双网

#	文件名称	文件大小
1	18-8 Oversized Washer, 3.2 mm ID, 9 mm OD, .7 mm Thickness, ECS, Supercapacitor Enclosure.SLDPRT	81.3 KB
2	18-8 SHCS, M3 x 0.5 mm Thread, 5 mm Long, ECS, Supercapacitor Enclosure.SLDPRT	518 KB
3	18-8 SHCS, M3 x 0.5 mm Thread, 6 mm Long, ECS, Supercapacitor Enclosure.SLDPRT	567 KB
4	279175 Camo Deep Forest Green spray paint, back side.jpeg	2.81 MB
5	3V, 0.8A Solar Panel, 3V Supercapacitor Enclosure, Exploded View.JPG	129 KB
6	3V, 0.8A Solar Panel, 3V Supercapacitor Enclosure.SLDASM	5.11 MB
7	3V, 0.8A Solar Panel, 3V Supercapacitor Enclosure.STEP	31.9 MB
8	3V, 0.8A Solar Panel, 3V Supercapacitor Enclosure.x_b	7.41 MB
9	3V, 450F Ultracapacitor, TPLH-3R0-450SS35X71, ECS, Supercapacitor Enclosure.SLDPRT	2.39 MB
10	3d printed parts assembled, 3V, 0.8A Solar Panel, 3V Supercapacitor Enclosure.jpeg	2.12 MB
11	3d printed parts close up, 3V, 0.8A Solar Panel, 3V Supercapacitor Enclosure.jpeg	2.32 MB
12	3d printed parts, 3V, 0.8A Solar Panel, 3V Supercapacitor Enclosure.jpeg	2.55 MB
13	Base, SPSFC.3MF	70.4 KB
14	Base, SPSFC.SLDPRT	293 KB
15	Bottom Subassy, IP67 Clear Cover Junction Box, Supercapacitor Enclosure.SLDASM	576 KB
16	Cable Gland PG9, Enclosure, IP67 Clear Cover Junction Box, Supercapacitor Enclosure.SLDPRT	670 KB
17	Charged to full capacity.jpeg	2.65 MB
18	Cover, IP67 Clear Cover Junction Box, Supercapacitor Enclosure.SLDPRT	573 KB
19	DIN Rail, Aluminum, 35 mm Wide, 100 mm Length, ECS, Supercapacitor Enclosure.SLDPRT	358 KB
20	Description.txt	2.51 KB
21	Din Rail Terminal Block with Lever, ECS, Supercapacitor Enclosure.SLDPRT	1.95 MB
22	Diode Polarity Sticker, IP67 Clear Cover Junction Box, Supercapacitor Enclosure.SLDPRT	996 KB
23	Electrical Connections Subassy, Supercapacitor Enclosure.SLDASM	2.62 MB
24	Enclosure, IP67 Clear Cover Junction Box, Supercapacitor Enclosure.SLDPRT	666 KB
25	Front View, supercapacitor and terminal blocks setup.jpeg	1.48 MB
26	Ground Connection, Copper Wire, SPSFC.SLDPRT	56.3 KB
27	Ground Connection, Terminal Block Connection Copper Wire, SPSFC.SLDPRT	59.4 KB
28	Ground Connection, Terminal Block Connection Wire Insulation, SPSFC.SLDPRT	70 KB
29	Ground Connection, Wire Insulation, SPSFC.SLDPRT	52.5 KB
30	IP67 Clear Cover Junction Box, Supercapacitor Enclosure.SLDASM	2.34 MB
31	Input Solar Panel Wiring Here Sticker, IP67 Clear Cover Junction Box, Supercapacitor Enclosure.SLDPRT	425 KB
32	M3 X 3-12 mm Length, Brass Knurled Insert, ECS, Supercapacitor Enclosure.SLDPRT	1.26 MB
33	M4 Insert, IP67 Clear Cover Junction Box, Supercapacitor Enclosure.SLDPRT	600 KB
34	M4 x 20 mm Length, SSPFHS, IP67 Clear Cover Junction Box, Supercapacitor Enclosure.SLDPRT	992 KB
35	Main Connection Insulation, SPSFC.SLDPRT	51.4 KB
36	Mounting Spacer with Integrated Locating Pin, SPSFC.3MF	17.9 KB
37	Mounting Spacer with Integrated Locating Pin, SPSFC.SLDPRT	92.2 KB
38	O-ring, IP67 Clear Cover Junction Box, Supercapacitor Enclosure.SLDPRT	260 KB
39	Polycrystalline Solar Panel, 3V, 400 mA, SPSFC.SLDPRT	822 KB
40	Positive Connection, Copper Wire, SPSFC.SLDPRT	58.2 KB
41	Positive Connection, Terminal Block Connection Copper Wire, SPSFC.SLDPRT	60.1 KB
42	Positive Connection, Terminal Block Connection Wire Insulation, SPSFC.SLDPRT	71.2 KB
43	Positive Connection, Wire Insulation, SPSFC.SLDPRT	56.5 KB
44	Positive and Ground Connection, Copper Wire Subassy, SPSFC.SLDASM	57.8 KB
45	Positive and Ground Connection, Terminal Block Subassy, SPSFC.SLDASM	112 KB
46	Rear View, supercapacitor and terminal blocks setup.jpeg	1.7 MB
47	SR560 Schottky Barrier Rectifier Diode, 5A, 60V, DO-201AD, ECS, Supercapacitor Enclosure.SLDPRT	98.9 KB
48	Solar Panel Soldering Fixture and Case.SLDASM	391 KB
49	Top Cover Subassy, IP67 Clear Cover Junction Box, Supercapacitor Enclosure.SLDASM	1.04 MB
50	Top View, supercapacitor and terminal blocks setup.jpeg	1.83 MB
51	Ultracapacitor Mounting Bracket Base, ECS, Supercapacitor Enclosure.SLDPRT	95.6 KB
52	Ultracapacitor Mounting Bracket, ECS, Supercapacitor Enclosure.SLDPRT	148 KB
53	Ultracapacitor Subassy, ECS, Supercapacitor Enclosure.SLDASM	1.88 MB
54	Wire Routing Tube, IP67 Clear Cover Junction Box, Supercapacitor Enclosure.SLDPRT	62.2 KB
55	Wiring Subassy, SPSFC.SLDASM	86.3 KB
56	X Hole to Hole Distance Template, Standoffs, 3V, 0.8A Solar Panel, 3V Supercapacitor Enclosure.SLDPRT	78.5 KB
57	~$Ground Connection, Terminal Block Subassy, SPSFC.SLDASM	4 B
58	~$Positive Connection, Copper Wire Subassy, SPSFC.SLDASM	4 B
